9J1–14 RESTRAINT CONTROL SYSTEM
DTC Chart Test Description:
Number(s) below refer to step number(s) on the
diagnostic chart:
2. This test determines whether the malfunction is in
the SDM.
3. This test verifies proper connection of the yellow
2–pin connector.
4. This test checks for proper contact and/or corrosion
of the yellow 2–pin connector terminals.
5. The test checks for a malfunctioning passenger air
bag assembly.
6. This test determines whether the malfunction is due
to high resistance in the wiring.
Diagnostic Aids:
An intermittent condition is likely to be caused by a poor
connection at the passenger air bag assembly harness
connector terminals "1" and "2", SDM terminal "15" and
"16", or a poor wire to terminal connection in CKTs
IB07–YEL/GRN and IB08–YEL/RED. This test for this
diagnostic trouble code is only run while the "AIR BAG"
warning lamp is performing the bulb check, unless DTC
17 or DTC 26 is detected. When a scan tool "Clear
Codes" command is issued and the malfunction is still
present, the DTC will not reappear until the next ignition
cycle.
