Mechanical Adjustment; Adjustment Of The Scanner Motor Timing Belt - Konica Minolta Bizhub C350 Service Manual

Mechanical adjustment

6. Mechanical adjustment
6.1

Adjustment of the Scanner Motor Timing Belt

This adjustment must be made in the following case:
• The Scanner Motor Assy has been removed.
• The Scanner Drive Cables have been rewound.
1. Remove the IR Rear Cover.
2. Remove 16 screws and the reinforcement frame.
[2]
[2] [3]
bizhub C350 Field Service Ver 2.0 April 2004
3. Loosen the three screws that secure
[1]
4036fs3036c0
4. With the Scanner drive gear set
[4]
5. Tighten the three screws [2] to fix the
[2]
4036fs3037c0
3-100
the Scanner Motor mounting bracket
[1].
screw [2] located on the right-hand
side as shown on the left, slide the
Scanner Motor Assy [3] to the left
and check that it is returned to the
original position by the tension of the
spring [4]. Perform this step three
times.
Scanner Motor Assy into position.
