Periodical check
1.5.7

Cleaning of Synchronizing Roller

1.5.8

Paper Dust Remover

[1]
[3]
[1]
bizhub C350 Field Service Ver. 2.0 April 2004
1. Open the Right Door.
2. Remove the Paper Dust Remover.
☞ See 2-16 for Replacing the Paper
[1]
Dust Remover.
3. Using a soft cloth dampened with
alcohol, wipe the Synchronizing Roll-
ers [1] clean of dirt.
4036fs2502c0
[2]
A. Cleaning Procedure
1. Open the Right Door.
2. Pushing the hook [1] with a blue
label inward, remove the Paper Dust
Remover [2].
4036fs2501c0
3. Using a brush, whisk dust off the
Paper Dust Remover [3].
[2]
B. Replacing Procedure
1. Open the Right Door.
2. Pushing the hook [1] with a blue
label inward, remove the Paper Dust
Remover [2].
3. Remove the Ozone Filter.
☞ 2-21
4. Select "Tech. Rep. Mode"
4036fs2501c0
"Counter"
count of "Paper Powder Filter/Ozone
Filter."
2-16
→
→
"Life" and clear the
