Periodical check
[3]
[5]
[7]
[9]
bizhub C350 Field Service Ver. 2.0 April 2004
[4]
4036fs2019c0
[6]
4036fs2020c1
[8]
4036fs2021c1
4036fs2592c0
2-10
4. Open the Vertical transport door.
5. Remove two Claws [3] and the Verti-
cal transport door [4].
6. Remove two Screws [5], and remove
the Jam processing cover [6].
7. Remove two Screws [7] and the Sep-
aration Roller 2 installation plate
Assy [8].
8. Using a soft cloth dampened with
alcohol, wipe the Separation Roller
[9].
