1.3.4

Upper Door

[4]
[3]
[7]
[6]
1.3.5

Finisher Tray Upper Cover

[1]
[2]
bizhub C350 Field Service Ver.1.0 Mar. 2004
1. Open the Upper Door [1], and
[1]
2. Remove the Door Band [3].
3. Remove the screw [4], and remove
[2]
4583fs2531c0
4. Remove the screw [5], remove the
[5]
4583fs2532c0
1. Remove the Front Cover.
☞ 2-3
2. Remove the Rear Cover.
☞ 2-3
3. Remove the Upper Door.
☞ 2-4
4. Unplug the connector [1].
4583fs2533c0
5. Unplug the connector [3] while hold-
[3]
4583fs2534c0
2-4
remove the Door Band Holder [2] by
turning it clockwise.
the grounding wire.
Finisher Tray Rear Cover [6], and
remove the Upper Door [7].
ing up the Finisher Tray Upper Cover
[2], and remove the Finisher Tray
Upper Cover [2].
