C0B76:Punch Side Registration Motor malfunctions

A. Detection timing
Malfunction code
The Side Registration Home Sensor (PI2P-PK) is not unblocked even after the
lapse of a given period of time after the Punch Side Registration Unit has started
moving from its home position.
C0B76
The Side Registration Home Sensor (PI2P-PK) is not blocked even after the lapse
of a given period of time after the Punch Side Registration Unit has started moving
from a position not the home position.
B. Action
Side Registration Home Sensor (PI2P-PK)
Step
Check the sensor connectors for proper
1
connection, and correct as necessary.
2 PI2P-PK I/O, sensor check
3 PWB-B PK replacement
Relevant electrical parts
Action
4-19
Description
Punch Control Board (PWB-B PK)
WIRING DIAGRAM
Control signal
-
PWB-B PK J1006 PK-3
-
Trouble code
Location
(Electrical compo-
nents)
-
C-2
C-1
