Adjustment Of The Document Edge Guide Reference Position - Konica Minolta Bizhub C350 Service Manual

bizhub C350 Field Service Ver.1.0 Mar. 2004
4.2

Adjustment of the document edge guide reference position

Adjustment standard: Displacement of the document edge should be within 4 ± 1 mm to the
FD scale.
A. Adjustment procedure
A
B
[2]
1. Place the chart furnished with the
[1]
2. Set up the following functions:
• Auto Paper
• 1-sided original / 1-side copy
4582fs3508c0
3. Press the "Start" key.
4. Fold the copy in half.
5. With reference to the crease, check
• If the deviation falls outside the speci-
4582fs3509c0
fied range, use the following proce-
dure to make an adjustment.
6. Loosen screw [2] (two on the front
7. Make recheck.
4582fs3510c0
3-7
Mechanical adjustment
Document Feeder in the document
feeding tray [1] (with the side having
an arrow facing up).
to see if the arrow is on the side of A
or B.
Specifications: ± 2 mm from the cen-
ter
side and three on the backside) on
the document feeding tray.
If the crease deviates on the side of
A, move the tray to the front.
If the crease deviates on the side of
B, move the tray to the rear.
