bizhub C350 Field Service Ver.2.0 April 2004
[7]
4.3.24

Inverter Board

[2]
[4]
[1]
4.3.25

Multi Bypass Unit

[6]
4036fs2151c0
[1]
[3]
4036fs2152c0
[2]
[1]
4036fs2078c1
[3]
4036fs2079c1
2-59
5. Remove the Lever [6], and remove
the Tray 2 Paper Size Board [7].
1. Remove the Scanner Assy.
☞ 2-68
2. Remove four Screws [1], Flat Cable
[2] and Connector [3], and remove
the Inverter Board [4].
1. Remove two Screws [1], and remove
the Tray 2 Rear Right Cover [2].
2. Remove three Connectors [3].
