bizhub C350 Field Service Ver. 2.0 April 2004
3.

Power supply trouble

3.1

Machine is not Energized at All (PU1 Operation Check)

Power Switch (SW1)
Control Board (PWB-MC)
Step Check Item
Is a power voltage supplied across PJ1PU1-1
1 and 2 on PU1?
2 Are the fuses (F1 and F2) on PU1 conducting?
Is DC24 V being output from PJ5PU1-1 on
3
PU1?
4 Is DC5 V being input to PJ10PU1-1 on PU1?
Is DC5 V being input to PJ1MC-7 on the Con-
5
trol Board? (LED on PWB-MC does not blink.)
3.2

Control panel indicators do not light.

Image Processing Board (PWB-C)
Control Panel (UN201)
Step Check Item
Is the I/F cable between the Scanner and
1
engine connected properly?
Is a power voltage being applied across
2 PJ1PU1-1 and 2 on PU1?
3 Is the fuse (F1,F2) on PU1 conducting?
Is DC5 V being output from PJ10PU1-5 on
4
PU1 and DC24 V from PJ5PU1-3?
5 Is PJ12C on PWB-C securely connected?
Is CN1UN201on UN201 securely connected?
6
Relevant Electrical Parts
DC Power Supply (PU1)
WIRING
DIAGRAM
(Location)
26-G
—
23-E
23-C
14-E
Relevant Electrical Parts
DC Power Supply (PU1)
WIRING
DIAGRAM
(Location)
—
26-G
—
22-H
19-Y
24-F
4-49
Power supply trouble
Result Action
NO Check WIRING
between the wall outlet
and PJ1PU1.
NO Change PU1.
NO
Change PU1.
NO Change PU1.
NO Change PU1.
YES Change PWB-MC
Result Action
NO Reconnect or change
the I/F cable.
NO Check the WIRING from
the wall outlet to SW1
PJ1PU1.
NO Change PU1.
NO
Change PU1.
NO Reconnect.
NO Reconnect.
YES Change UN201.
Change PWB-C.
