TROUBLESHOOTING
Problem
Embroidery pattern
Thread is twisted.
does not sew out
correctly
Fabric was not inserted into the frame correctly
(fabric was loose, etc.).
Stabilizing material was not attached.
There was an object placed near the machine,
and the carriage or embroidery frame hit the
object during sewing.
Fabric outside the frame edges interferes with
the sewing arm, so the embroidery unit cannot
move.
Fabric is too heavy, so the embroidery unit
cannot move freely.
Fabric is hanging off the table.
Fabric is snagged or caught on something.
Embroidery frame was removed during sewing
(for example, to reset the bobbin). The presser
foot was bumped or moved while removing or
attaching the embroidery frame, or the
embroidery unit was moved.
Stabilizer is incorrectly attached, for example, it
is smaller than the embroidery frame.
Loops appear on the
The thread tension is incorrectly set.
surface of the fabric
The tension of the upper thread is incorrectly set
when embroidering
for the combination of the fabric, thread and
pattern being used.
The combination of the bobbin case and bobbin
thread is incorrect.
Machine does not
There is no pattern selected.
operate
"Start/Stop" button was not pushed.
Main power switch is not turned on.
Presser foot is not lowered.
"Start/Stop" button was pushed with the foot
controller attached.
The "Start/Stop" button was pressed while the
machine is set for the sewing speed controller to
control the zigzag stitch width.
All keys and buttons have been locked by
Embroidery unit does
There is no pattern selected.
not operate
Main power switch is not turned on.
Embroidery unit is not attached correctly.
Embroidery frame was attached before the unit
was initialized.
Nothing happens,
The screen has been locked.
even if the LCD
display is pressed
The fabric feeds in the
The feed mechanism is damaged.
opposite direction.
The LCD screen is
Condensation has formed on the LCD screen.
fogged up.
346
Cause
.
Solution
Use scissors, etc., to cut the twisted thread
and remove it from the race, etc.
If the fabric is not stretched tight in the frame,
the pattern may turn out poorly or there may
be shrinkage of the pattern. Set the fabric into
the frame correctly.
Always use stabilizing material, especially
with stretch fabrics, lightweight fabrics, fabrics
with a coarse weave, or fabrics that often
cause pattern shrinkage. See your authorized
dealer for the proper stabilizer.
If the frame bumps something during sewing,
the pattern will turn out poorly. Do not place
anything in the area where the frame may
bump it during sewing.
Reinsert the fabric in the embroidery frame so
that the excess fabric is away from the sewing
arm, and rotate the pattern 180 degrees.
Place a large thick book or similar object
under the arm head to lightly lift the heavy
side and keep it level.
If the fabric is hanging off the table during
embroidery, the embroidery unit will not move
freely. Place the fabric so that it does not hang
off the table or hold the fabric to keep it from
dragging.
Stop the machine and place the fabric so that
it does not get caught or snagged.
If the presser foot is bumped or the
embroidery unit is moved during sewing, the
pattern will not turn out. Be careful when
removing or reattaching the embroidery frame
during sewing.
Attach the stabilizer correctly.
Adjust the thread tension.
Use the embroidery needle plate cover.
Change the bobbin case or bobbin thread so
that the correct combination is used.
Select a pattern.
Press the "Start/Stop" button.
Turn the main power to ON.
Lower the presser foot.
Remove the foot controller, or use the foot
controller to operate the machine.
Use the foot controller instead of the "Start/
Stop" button to operate the machine, or set
the Width control to OFF in the Sewing
settings.
Press
to unlock all keys and
buttons.
Select a pattern.
Turn the main power to ON.
Reattach the embroidery unit correctly.
Perform the initialization process correctly.
Press either of the following keys to unlock the
screen.
Contact your dealer or the nearest authorized
service center.
After a while, the cloudiness will disappear.
Page
203
200
218
203
218
229
200
233 - 235
219
218
91, 156, 190, 265
15
26
15
73
35, 73
65, 67
190, 265
26
188
188
