d
Press
.
Note
• Attach embroidery foot "W" before pressing
. The embroidery foot "W" lowers
and check the fabric thickness, to help the
built-in camera recognize the embroidery
positioning sticker.
e
Following message appears. Press
→ The built-in camera automatically searches for the
embroidery positioning sticker, and then the
carriage is moved so that the center of the
embroidery pattern is aligned with the center of the
embroidery positioning sticker. Regardless of the
setting selected in the machine settings screen, the
brightness of the light changes to "5" while the built-
in camera searches for the embroidery positioning
sticker.
Note
• If the following warning message appears,
touch
and reposition the embroidery
positioning sticker so the pattern is within
the embroidery field, and then press
again.
CONFIRMING THE PATTERN POSITION
f
A reminder message appears. Remove the
embroidery positioning sticker from the
fabric, and press
*
To remove the embroidery positioning sticker more
easily, press
moves slightly forward and away from under the
needle. After the embroidery positioning sticker is
removed, press
.
g
Press the "Start/Stop" button to begin
embroidering.
*
See "Sewing Embroidery Patterns" on page 219.
Note
• After the included embroidery positioning
stickers are used up, optional stickers are
available. For details, refer to "Options" on
page 20.
.
so that the embroidery frame
.
5
215
