This section lists the supplemental characteristics of the Keysight N6705C DC Power Analyzer.
Supplemental characteristics are not warranted but are descriptions of performance determined
either by design or by type testing. All supplemental characteristics are typical unless otherwise
noted.
Specifications and characteristics are subject to change without notice.
Complete specifications and supplemental characteristics information for all power
modules are included in the
Specifications
Supplemental Characteristics
Characteristic
Maximum total power available for
power modules:
Front panel output terminals maximum
current rating:
BNC trigger connectors
IO:
Maximum voltage:
Minimum input pulse:
Output pulse:
USB current ratings
Front panel USB:
Rear panel USB:
Data storage of internal flash memory:
Protection Response
INH Input:
Fault on coupled output:
Command Processing Time:
44
Keysight N6700 DC Power Analyzer Family
Guide.
Keysight N6705C
600 W
20 A
Digital TTL level compatible
5 V
> 6 ns, positive going; > 90 ns, negative going
10 ms, negative-going
200 mA
300 mA
4 Gbytes
5 µs from receipt of inhibit to start of shutdown
< 10 µs from receipt of fault to start of shutdown
≤ 1 ms from receipt of command to start of output change
Keysight N6705C Operating and Service Guide
