8 Verification and Calibration
Test Record Form - Keysight N6734B and N6744B
N6734B and N6744B
Test Description
Voltage Programming & Readback
Minimum voltage (Vout):
Voltage measured over interface:
High voltage (Vout):
Voltage measured over interface:
CV Load Effect:
CV Source Effect:
CV Ripple and Noise
peak-to-peak:
rms:
Transient response
Voltage @ 200 μs:
Current Programming & Readback
Minimum current (Iout):
Current measured over interface:
High current (Iout):
Current measured over interface:
CC Load Effect:
CC Source Effect:
Test Description
Voltage Programming & Readback Min Voltage:
Voltage Programming & Readback High Voltage:
CV Load Effect, Source Effect, Ripple and Noise:
Transient Response:
Current Programming & Readback Min Current:
Current Programming & Readback High Current:
CC Load Effect, Source Effect:
416
Report Number ______
Model Min. Specs
Constant Voltage Tests
Both + 5 mV
Both Vout – 35 mV
Both 34.93 V
Both Vout – 70 mV
Both – 11 mV
Both – 4 mV
Both N/A
Both N/A
N6734B – 200 mV
N6744B – 300 mV
Constant Current Tests
Both – 15 mA
Both Iout – 4 mA
N6734B 1.47775 A
N6744B 2.9755 A
N6734B Iout – 6.25 mA
N6744B Iout – 8.5 mA
Both – 2 mA
Both – 1 mA
N6734B Setting
40 mV, 1.5 A
35 V, 1.5 A
35 V, 1.5 A
35 V, from 0.75 A to 1.5 A
5 mA, 35 V
1.5 A, 35 V
1.5 A, 35 V
Date__________
Results
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
N6744B Setting
40 mV, 3 A
35 V, 3 A
35 V, 3 A
35 V, from 1.5 A to 3 A
5 mA, 35 V
3 A, 35 V
3 A, 35 V
Keysight N6705C Operating and Service Guide
Max. Specs
+ 75 mV
Vout + 35 mV
35.07 V
Vout + 70 mV
+ 11 mV
+ 4 mV
+ 15 mV
+ 5 mV
+ 200 mV
+ 300 mV
+ 25 mA
Iout + 4 mA
1.52225 A
3.0245 A
Iout + 6.25 mA
Iout + 8.5 mA
+ 2 mA
+ 1 mA
