9 Service and Maintenance

Replaceable Parts

Parts List

Location Diagrams
Parts List
The following table lists the available replaceable parts. The location diagrams below the table show
the location of these parts.
Reference N6705C Part number
Designator
A1 N6705-66501
N6705-66511
A2 5067-5202
A3 5067-5096
A4 5067-5094
5067-6629
A5 0950-5355
A6 Contact Keysight Service and
Support
1 5003-2223
2 5003-2222
3 5003-2221
4 5040-1741
5 5043-1310
6 5043-1305
7 5043-1306
8 5067-6094
1254-2328
9 5067-6095
1254-2330
466
Electrical Assemblies
Processor carrier PCA
Processor carrier without USB connector - Option AKY
Bias PCA
Front panel PCA
Standard binding post PCA
Option RBP binding post PCA
Bulk supply (1200W single-output)
P600 processor (installs on Processor Carrier board)
Individual Parts
Side cover (qty 2)
Bottom cover
Top cover
Window
Keypad
12 mm knob (qty 5)
18 mm knob (qty 2)
Standard red biding post (qty 8)
Recessed red biding post - Option RBP (qty 8)
Standard black binding post (qty 8)
Recessed black binding post - Option RBP (qty 8)
Description
Keysight N6705C Operating and Service Guide
