8 Verification and Calibration
Step 2. Select the first voltage calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P1 measured data" Enter the data from the external
DMM. Press Select when done.
Step 3. Select the second voltage calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P2 measured data"Enter the data from the external DMM.
Press Select when done.
Press Next to finish calibration.
Step 4. Repeat steps 1 through 3 for the 6 V positive limit range. This time, select the Low range.
Auxiliary Voltage Measurement - Models N6781A, N6785A
Step 1. Connect the auxiliary input terminals to the output terminals of model N6781A. Also connect
the voltage input of the Keysight 3458A to the output terminals of model N6781A (see
Step 2. Select the auxiliary voltage measurement input of output 1.
Front Panel Menu Reference
From the Calibration menu, select Voltage, Aux Measurement. Then select Start.
Step 3. Select the first voltage calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P1 measured data" Enter the data from the external DMM.
Press Select when done.
Step 4. Select the second voltage calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P2 measured data" Enter the data from the external DMM.
Press Select when done. Press Next to finish calibration.
Step 5. Select the third voltage calibration point for the negative range and enter the data. This value
should be negative.
402
SCPI Command
CAL:LEV P1
*OPC?
CAL:DATA <data>
SCPI Command
CAL:LEV P2
*OPC?
CAL:DATA <data>
SCPI Command
CAL:VOLT:MEAS:AUX (@1)
SCPI Command
CAL:LEV P1
*OPC?
CAL:DATA <data>
SCPI Command
CAL:LEV P2
*OPC?
CAL:DATA <data>
Keysight N6705C Operating and Service Guide
Cal Setup E).
