8 Verification and Calibration
Test Record Form - Keysight N6732B and N6742B
N6732B and N6742B
Test Description
Voltage Programming & Readback
Minimum voltage (Vout):
Voltage measured over interface:
High voltage (Vout):
Voltage measured over interface:
CV Load Effect:
CV Source Effect:
CV Ripple and Noise
peak-to-peak:
rms:
Transient response
Voltage @ 200 μs:
Voltage @ 200 μs with Option 760/761:
Current Programming & Readback
Minimum current (Iout):
Current measured over interface:
High current (Iout):
Current measured over interface:
CC Load Effect:
CC Source Effect:
Test Description
Voltage Programming & Readback Min Voltage:
Voltage Programming & Readback High Voltage:
CV Load Effect, Source Effect, Ripple and Noise:
Transient Response:
Current Programming & Readback Min Current:
Current Programming & Readback High Current:
CC Load Effect, Source Effect:
414
Report Number ______
Model Min. Specs
Constant Voltage Tests
Both − 4 mV
Both Vout − 20 mV
Both 7.973 V
Both Vout − 28 mV
Both – 6 mV
Both – 2 mV
Both N/A
Both N/A
N6732B – 80 mV
N6742B – 100 mV
N6732B – 100 mV
N6742B – 125 mV
Constant Current Tests
Both + 20 mA
Both Iout − 10 mA
N6732B 6.2206 A
N6742B 12.46 A
N6732B Iout − 19.37 mA
N6742B Iout − 29 mA
Both – 2 mA
Both – 1 mA
N6732B Setting
15 mV, 6.25 A
8 V, 6.25 A
8 V, 6.25 A
8 V, from 3.125 A to 6.25 A
40 mA, 8 V
6.25 A, 8 V
6.25 A, 8 V
Date__________
Results
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
N6742B Setting
15 mV, 12.5 A
8 V, 12.5 A
8 V, 12.5 A
8V, from 6.25A to 12.5A
40 mA, 8 V
12.5 A, 8 V
12.5 A, 8 V
