[SOURce:]ARB:CURRent:STAircase:STARt[:LEVel] <
[SOURce:]ARB:CURRent:STAircase:STARt[:LEVel]? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:STAircase:STARt[:LEVel] <
[SOURce:]ARB:VOLTage:STAircase:STARt[:LEVel]? [MIN|MAX,] (@<chanlist>)
Specifies the initial current or voltage before the staircase occurs. Referenced to I0 and V0 in the
Staircase diagrams.
[SOURce:]ARB:SEQuence:STEP:CURRent:STAircase:STARt[:LEVel] <
[SOURce:]ARB:SEQuence:STEP:CURRent:STAircase:STARt[:LEVel]? [MIN|MAX,] <
[SOURce:]ARB:SEQuence:STEP:VOLTage:STAircase:STARt[:LEVel] <
[SOURce:]ARB:SEQuence:STEP:VOLTage:STAircase:STARt[:LEVel]? [MIN|MAX,] <
Specifies the initial current or voltage before the staircase occurs for Arb sequence steps.
The difference between the start level and the end level is divided equally among the
number of steps.
Parameter
Current: 0 - maximum|MIN|MAX, *RST MIN
Voltage: 0 - maximum|MIN|MAX, *RST MIN
The maximum value varies, depending on the current or voltage
rating of the power module.
Step 0 - 99, *RST 0
Programs a start level current: ARB:CURR:STA:STAR 1,(@1)
Programs a start level voltage: ARB:VOLT:STA:STAR 1,(@1)
Programs an start level for step 0:ARB:SEQ:STEP:CURR:STA:STAR 1, 0,(@1)
[SOURce:]ARB:CURRent:STAircase:STARt:TIMe <
[SOURce:]ARB:CURRent:STAircase:STARt:TIMe? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:STAircase:STARt:TIMe<
[SOURce:]ARB:VOLTage:STAircase:STARt:TIMe? [MIN|MAX,] (@<chanlist>)
Specifies the delay in seconds after the trigger is received, but before the staircase occurs. Referenced
to t0 in the Staircase diagrams.
[SOURce:]ARB:SEQuence:STEP:CURRent:STAircase:STARt:TIMe <
[SOURce:]ARB:SEQuence:STEP:CURRent:STAircase:STARt:TIMe? [MIN|MAX,] <
[SOURce:]ARB:SEQuence:STEP:VOLTage:STAircase:STARt:TIMe <
[SOURce:]ARB:SEQuence:STEP:VOLTage:STAircase:STARt:TIMe? [MIN|MAX,] <
Specifies the delay in seconds after the trigger is received, but before the staircase occurs for Arb
sequence steps.
Keysight N6705C Operating and Service Guide
value
>, (@<chanlist>)
value
>, (@<chanlist>)
value
>, <
value
>, <
Typical Return
<start value>
value
>, (@<chanlist>)
value
>, (@<chanlist>)
value step#
>, <
value step#
>, <
7 SCPI Programming Reference
step#
>, (@<chanlist>)
step#
>, (@<chanlist>)
step#
>, (@<chanlist>)
step#
>, (@<chanlist>)
(none)
>, (@<chanlist>)
step#
>, (@<chanlist>)
>, (@<chanlist>)
step#
>, (@<chanlist>)
