Voltage Commands

Voltage commands program the output voltage and voltage protection functions. The SOURce
keyword is optional in the following commands.
[SOURce:]VOLTage[:LEVel][:IMMediate][:AMPLitude] <value>, (@<chanlist>)
[SOURce:]VOLTage[:LEVel][:IMMediate][:AMPLitude]? [MIN|MAX,] (@<chanlist>)
[SOURce:]VOLTage[:LEVel]:TRIGgered[:AMPLitude] <value>, (@<chanlist>)
[SOURce:]VOLTage[:LEVel]:TRIGgered[:AMPLitude]? [MIN|MAX,] (@<chanlist>)
Sets the immediate voltage level and the triggered voltage level when the output is in constant
voltage mode. The triggered level is a stored value that is transferred to the output when an output
Step is triggered.Units are in volts. The maximum value depends on the voltage rating of the unit.
Parameter
0 - maximum|MIN|MAX, *RST 0
The maximum value is 102% of the voltage rating of
the power module
Sets the output voltage level to 20 V: VOLT 20, (@1)
Sets the triggered voltage level to 25 V: VOLT:TRIG 25, (@1)
The query returns the programmed voltage level in the form +n.nnnnnnE+nn for each channel
specified. Multiple responses are separated by commas.
[SOURce:]VOLTage:BWIDth LOW|HIGH1|HIGH2|HIGH3, (@<chanlist>)
[SOURce:]VOLTage:BWIDth? (@<chanlist>)
Sets the voltage bandwidth. This lets you optimize output response time with capacitive loads. Refer
to Output Bandwidth for additional information
These compensation modes only apply when the unit is operating in voltage priority mode.
LOW - is optimized for stability with a wide range of output capacitors (from 0 to 150 μF).
HIGH1 - provides maximum up-programming speed and fastest transient response when the output
capacitance is restricted to 0–1 μF.
HIGH2 - provides maximum up-programming speed and fastest transient response when the output
capacitance is restricted to 0–7 μF.
HIGH3 - provides maximum up-programming speed and fastest transient response when the output
capacitance is restricted to 7–150 μF.
Parameter
LOW|HIGH1|HIGH2|HIGH3, *RST LOW
Sets the voltage bandwidth to HIGH3: VOLT:BWID HIGH3, (@1)
Keysight N6705C Operating and Service Guide
7 SCPI Programming Reference
Typical Return
<voltage level>
Typical Return
HIGH1, HIGH2, HIGH3, or LOW
