Front Panel Menu Reference
Display shows: "Enter measured data"
Measure the current with the Keysight 3458A and enter the data. Press Select
when done.
Negative Current Limit Calibration
Step 1. Connect the Keysight 3458A, current shunt, and a power supply to the output (see
G). Connect plus to plus, minus to minus. Set the external power supply to 3V, 3A.
Step 2. Select the negative-current range. The value to select the range must be negative and the
maximum current of the range.
Front Panel Menu Reference
From the Calibration menu, select Current, Current Limit. Then select Start.
Step 3. Select the first current calibration point and enter the data. This value should be negative.
Front Panel Menu Reference
Display shows: "Enter P1 measured data" Calculate the shunt current (I=V/R)
and enter the data.
Press Select when done.
Step 4. Select the second current calibration point and enter the data. This value should be negative.
Front Panel Menu Reference
Display shows: "Enter P2 measured data"
Calculate the shunt current (I=V/R) and enter the data. Press Select when done.
Press Next to finish calibration.
Enter a Calibration Date, Save, and Log Out
Front Panel Menu Reference
From the Calibration menu, select Date. Enter the date, then select Insert Date.
Then select Close.
From the Calibration menu, select Save. Select Save Calibration for all Outputs.
Then select Close.
From the Administrative Tools menu, select Administrator Login/Logout to log
out of the Admin menu.
Keysight N6705C Operating and Service Guide
8 Verification and Calibration
SCPI Command
CAL:LEV P1
*OPC?
CAL:DATA <data>
SCPI Command
CAL:CURR:LIM:NEG -2, (@1)
SCPI Command
CAL:LEV P1
*OPC?
CAL:DATA <data>
SCPI Command
CAL:LEV P2
*OPC?
CAL:DATA <data>
SCPI Command
To enter a calibration date:
CAL:DATE "<date>"
To save the calibration data:
CAL:SAVE
To exit calibration mode:
CAL:STAT OFF
Cal Setup
411
