Test Record Form - Keysight N6783A-BAT and N6783A-MFG
N6783A-BAT, '83A-MFG
Test Description
Voltage Programming & Readback
Minimum voltage (Vout):
Voltage measured over interface:
High voltage (Vout):
Voltage measured over interface:
CV Load Effect:
CV Source Effect:
CV Ripple and Noise
peak-to-peak:
rms:
Transient response 6 V
Voltage @ 45 μs:
Voltage @ 75 μs with Option 761:
Current Programming & Readback
Minimum current (Iout):
Current measured over interface:
High current (Iout):
Current measured over interface:
Low current measured over interface:
CC Load Effect:
CC Source Effect:
Negative Current Output:
Test Description
Voltage Programming & Readback Min Voltage:
Voltage Programming & Readback High Voltage:
CV Load Effect, Source Effect, Ripple and Noise:
Transient Response:
Current Programming & Readback Min Current:
Current Programming & Readback High Current:
Current Readback Low Current:
CC Load Effect, Source Effect:
Negative current output:
Keysight N6705C Operating and Service Guide
Report Number ______
Model Min. Specs
Constant Voltage Tests
Both − 5 mV
Both Vout − 5 mV
N6783A-BAT 7.982 V
N6783A-MFG 5.984 V
N6783A-BAT Vout − 9 mV
N6783A-MFG Vout − 8 mV
Both – 6 mV
Both – 2 mV
Both N/A
Both N/A
N6732B – 75 mV
N6742B – 90 mV
Constant Current Tests
Both + 3.2 mA
Both Iout − 0.6 mA
Both 2.9952 A
Both Iout − 3.6 mA
Both Iout − 225 µA
Both – 2 mA
Both – 1 mA
Both – 1.9942 A
N6783A-BAT Setting
15 mV, 3 A
8 V, 3 A
8 V, 3 A
6 V, from 0.15 A to 1.5 A
5 mA, 8 V
3 A, 8 V
150 mA, 8 V
3 A, 8 V
0 V, – 2 A
8 Verification and Calibration
Date__________
Results Max. Specs
_______ + 25 mV
_______ Vout + 5 mV
_______ 8.018 V
_______ 6.016 V
_______ Vout + 9 mV
_______ Vout +8 mV
_______ + 6 mV
_______ + 2 mV
_______ + 8 mV
_______ + 1.5 mV
_______ + 75 mV
_______ + 90 mV
_______ + 6.8 mA
_______ Iout + 0.6 mA
_______ 3.0048 A
_______ Iout + 3.6 mA
_______ Iout + 225 µA
_______ + 2 mA
_______ + 1 mA
_______ + 2.0058 A
N6783A-MFG Setting
15 mV, 3 A
6 V, 3 A
6 V, 3 A
6 V, from 0.15 A to 1.5 A
40 mA, 6 V
3, 6 V
150 mA, 6 V
3 A, 6 V
0 V, – 2 A
