3 Using the Source Functions
Trigger Source
Bus
IMMediate
EXTernal
To specify arbitrary waveforms as the output trigger response::
CURR:MODE ARB(@1)
VOLT:MODE ARB,(@1)
To select a BUS trigger source:
TRIG:ARB:SOUR BUS
To select the immediate trigger source:
TRIG:ARB:SOUR IMM
To select the rear panel trigger input BNC connector:
TRIG:ARB:SOUR EXT

Arb Triggers

For the arbitrary waveform to appear at the output terminals, the selected output must
be turned on before the Arb is run. When the arbitrary waveform runs, front panel
voltage and current controls as well as any remote voltage and current commands are
ignored until after the Arb completes.
From the front or rear panel
Depending upon the selected trigger source, you can trigger the arbitrary waveforms as follows:
Trigger Source
Arb Run/Stop Key
Rear Trigger Input
Once configured, the instrument will wait indefinitely for the trigger signal. If the trigger does not
occur, and you wish to cancel the arbitrary waveform, press the Arb Run/Stop key to stop the Arb.
From the remote interface:
To initiate the transient trigger system:
INIT:TRAN(@1)
106
Description
Selects a GPIB device trigger, *TRG, or <GET> (Group Execute Trigger).
Selects the immediate trigger source. This triggers the Arb immediately when the INITiate command is sent.
Selects the trigger input BNC connector on the rear panel. You must provide a low-true signal to the
connector.
Description
Press the Arb Run/Stop key to initiate and start the Arbs. All Arbs are triggered simultaneously. Press the
Arb Run/Stop key again to stop the Arbs.
Provide a low-true signal to the Trigger In BNC connector. The signal must persist for at least 2 micro-
seconds. All Arbs are triggered simultaneously.
