Test Record Form - Keysight N6754A and N6756A
N6754A and N6756A
Test Description
Voltage Programming & Readback
Minimum voltage (Vout):
Voltage measured over interface:
High voltage (Vout):
Voltage measured over interface:
CV Load Effect:
CV Source Effect:
CV Ripple and Noise
peak-to-peak:
rms:
Transient response
Voltage @ 100 μs:
Voltage @ 100 μs with Option 760/761:
Current Programming & Readback
Minimum current (Iout):
Current measured over interface:
High current (Iout):
Current measured over interface:
CC Load Effect:
CC Source Effect:
Test Description
Voltage Programming & Readback Min Voltage:
Voltage Programming & Readback High Voltage:
CV Load Effect, Source Effect, Ripple and Noise:
Transient Response:
Current Programming & Readback Min Current:
Current Programming & Readback High Current:
CC Load Effect, Source Effect:
Keysight N6705C Operating and Service Guide
Report Number ______
Model Min. Specs
Constant Voltage Tests
Both 0 mV
Both Vout − 25 mV
Both 59.939 V
Both Vout − 55 mV
Both – 2 mV
Both – 1.2 mV
Both N/A
Both N/A
Both – 90 mV
Both – 350 mV
Constant Current Tests
Both + 8 mA
Both Iout − 8 mA
N6754A 19.968 A
N6756A 16.071 A
N6754A Iout − 28 mA
N6756A Iout − 25 mA
Both – 5 mA
Both – 2 mA
N6754A Setting
25 mV, 5 A
60 V, 5 A
60 V, 5 A
15 V, from 10 A to 20 A
20 mA, 15 V
20 A, 15 V
20 A, 15 V
8 Verification and Calibration
Date__________
Results Max. Specs
_______ + 50 mV
_______ Vout + 25 mV
_______ 60.061 V
_______ Vout + 55 mV
_______ + 2 mV
_______ + 1.2 mV
_______ + 6 mV
_______ + 1 mV
_______ + 90 mV
_______ + 350 mV
_______ + 32 mA
_______ Iout + 8 mA
_______ 20.032 A
_______ 17.029 A
_______ Iout + 28 mA
_______ Iout + 25 mA
_______ + 5 mA
_______ + 2 mA
N6756A Setting
25 mV, 8.33 A
60 V, 8.33 A
60 V, 8.33 A
29 V, from 8.5 A to 17 A
20 mA, 29 V
17 A, 29 V
17 A, 29 V
