Front Panel Menu Reference

This is an overview of the front-panel menus. For a brief tutorial, refer to Use the Front Panel Menu.
Press the Menu key to access the front panel menus.
Menu Heading
Source Settings ►
Voltage and Current Settings...
Protection...
Advanced Protection...
Output On/Off Delays...
Output On/Off Coupling...
Output Grouping...
Advanced...
Ratings...
Arb ►
Arb Preview
Arb Selection...
Meter ►
All Outputs Meter View
Single Output Meter View
Meter Properties...
Scope ►
Standard View
Marker View
Scope Properties...
Marker Properties...
Horizontal Properties...
Datalogger ►
Standard View
Keysight N6705C Operating and Service Guide
Description
Configures the voltage and current settings, ranges, and emulation modes.
Configures the over-voltage and over-current protection. Enables output coupling so ALL
outputs are disabled when a fault occurs. Also clears output protection.
Enables/disables the output inhibit function.
Configures output on/off delays.
Couples specific outputs for the output on/off and delay function
Groups identical outputs for output paralleling function.
Configures advanced functions including slew rate, sensing, and power limit.
Displays power module ratings, serial number, firmware, and option information.
Displays the present status of the configured arbitrary waveforms.
Selects arbitrary waveforms for each output. Arb Properties configures the selected Arb.
Displays the meter view of all outputs.
Displays the meter view of the selected output.
Configures the meter view voltage and current measurement ranges.
Displays the standard scope view including vertical, horizontal, and trigger settings.
Displays the measurement markers and measurement calculations area.
Configures the scope traces and voltage and current measurement ranges for individual
outputs. Also configures the trigger source, mode, and horizontal offset.
Configures the measurements that appear on the bottom of the display in Marker view.
Configures the horizontal offset reference and sample points.
Displays the data log strip chart view including vertical, horizontal, and progress settings.
