8 Verification and Calibration

Test Equipment and Setups

Equipment Required

Measurement Setups
Equipment Required
The test equipment recommended for the verification and calibration procedures is listed below. If the
exact instrument is not available, substitute calibration standards of equivalent accuracy.
Instrument
Digital Multimeter
Current Shunt 2
Load Resistors
Electronic load 2
Keysight N6784A
GPIB controller
Oscilloscope
RMS Voltmeter
Differential Amplifier
Terminations
Variable voltage transformer
or AC source
RC – for N678xA transient
test
1 V = Verification C = Calibration
2 Dependent on rating of model being tested
372
Requirements
Resolution: 10 nV @ 1V
Readout: 8 1/2 digits
Accuracy: 20 ppm
15 A (0.1Ω)
30 A (0.1Ω)
50 A (0.05Ω)
25 Ω, 250 W, 1% (N6751A/52A/61A/62A)
4 Ω, 250 W, 1% (N6751A/52A/61A/62A)
20 kΩ, 1%, 1/8W (for option 1UA/2UA)
10 Ω, 1%, 1/8W (N678xA SMU)
10 kΩ, 1%, 1/8W (N678xA SMU)
1 MΩ, 1%, 1/8W (N678xA SMU)
150 V, 50 A minimum, with transient capability and a slew
rate of 833 kA/s or better
Load for N678xA SMU and N6783A (set to CC load mode)
Full GPIB capabilities
Sensitivity: 1 mV
Bandwidth Limit: 20 MHz
Probe: 1:1 with RF tip
True RMS
Bandwidth: 20 MHz
Sensitivity: 100 µV
Bandwidth: 20 MHz
1 – 50Ω BNC termination
2 – 50Ω 1/8 W termination resistors
Adjustable to highest rated input voltage
Power: 500 VA
Capacitor: 150 μF fixed film
Resistor 50 mΩ
Recommended Model
Keysight 3458A or equivalent
Guildline 9230A-15R
Guildline 9230A-30
Guildline 9230A-50
Vishay NH-250-25Ω-1%
Vishay NH-250-4Ω-1%
Keysight N3300A mainframe, with
N330xA modules
Keysight N6784A
Keysight 82350B or equivalent
Keysight DSO6054A or equivalent
Rhode and Schwartz Model URE3
or equivalent
LeCroy DA1855A, DA1850A, or
equivalent
Keysight 6813B or equivalent
EPCOS B32526R0157K
Vishay LVR01R0500FE70
Keysight N6705C Operating and Service Guide
Use 1
V, C
V, C
C
C
V, C
V, C
V, C
V, C
V, C
V
V, C
V
V
V
V
V
V
