8 Verification and Calibration
Test Record Form - Keysight N6736B and N6746B
N6736B and N6746B
Test Description
Voltage Programming & Readback
Minimum voltage (Vout):
Voltage measured over interface:
High voltage (Vout):
Voltage measured over interface:
CV Load Effect:
CV Source Effect:
CV Ripple and Noise
peak-to-peak:
rms:
Transient response
Voltage @ 200 μs:
Current Programming & Readback
Minimum current (Iout):
Current measured over interface:
High current (Iout):
Current measured over interface:
CC Load Effect:
CC Source Effect:
Test Description
Voltage Programming & Readback Min Voltage:
Voltage Programming & Readback High Voltage:
CV Load Effect, Source Effect, Ripple and Noise:
Transient Response:
Current Programming & Readback Min Current:
Current Programming & Readback High Current:
CC Load Effect, Source Effect:
418
Report Number ______
Model Min. Specs
Constant Voltage Tests
Both + 0 mV
Both Vout – 100 mV
Both 99.8 V
Both Vout – 200 mV
N6736B – 20 mV
N6746B – 30 mV
Both – 10 mV
Both N/A
Both N/A
N6736B – 500 mV
N6746B – 1000 mV
Constant Current Tests
Both – 8.5 mA
Both Iout – 2 mA
N6736B 0.4893 A
N6746B 0.9885 A
N6736B Iout – 2.75 mA
N6746B Iout – 3.5 mA
Both – 2 mA
Both – 1 mA
N6736B Setting
100 mV, 0.5 A
100 V, 0.5 A
100 V, 0.5 A
100 V, from 0.25 A to 0.5 A
1.5 mA, 100 V
0.5 A, 100 V
0.5 A, 100 V
Date__________
Results
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
N6746B Setting
100 mV, 1 A
100 V, 1 A
100 V, 1 A
100 V, from 0.5 A to 1 A
1.5 mA, 100 V
1 A, 100 V
1 A, 100 V
