Keysight Technologies N6705C Operating And Service Manual page 407

Front Panel Menu Reference
From the Calibration menu, select Current, Current Limit. Then select Start.
Step 3. Select the first current calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P1 measured data" Calculate the shunt current (I=V/R)
and enter the data. Press Select when done.
Step 4. Select the second current calibration point and enter the data. Wait a minimum of 1 minute for
the output current to stabilize before entering the data.
Front Panel Menu Reference
Wait1 minute and select Next.
Display shows: "Enter P2 measured data"
Calculate the shunt current (I=V/R) and enter the data. Press Select when done.
Press Next to finish calibration.
Resistance Calibration - Models N6781A, N6785A
Step 1. Connect an electronic load directly to the output terminals. Also connect the voltage input of
the Keysight 3458A to the output terminals (see
current to 0.95A.
Step 2. Select the 20 V resistance range of output 1.
Front Panel Menu Reference
From the Calibration menu, select Miscellaneous Resistance, 20 V Range. Then
select Start.
Step 3. Select the first resistance calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P1 measured data" Enter the data from the external DMM.
Press Select when done.
Step 4. Select the second resistance calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P2 measured data" Enter the data from the external DMM.
Press Select when done.
Keysight N6705C Operating and Service Guide
SCPI Command
For N6781A, N6782A, N6784A:
CAL:CURR:LIM:POS 3, (@1)
For N6785A, N6786A:
CAL:CURR:LIM:NEG -8, (@1)
SCPI Command
CAL:LEV P1
*OPC?
CAL:DATA <data>
SCPI Command
CAL:LEV P2
*OPC?
CAL:DATA <data>
Cal Setup F). Set the load to constant current mode,
CAL:RES 20 (@1)
CAL:LEV P1
*OPC?
CAL:DATA <data>
CAL:LEV P2
*OPC?
CAL:DATA <data>
8 Verification and Calibration
SCPI Command
SCPI Command
SCPI Command
407
