Export Function; Import Function - Keysight Technologies N6705C Operating And Service Manual

5 Using the System Functions

Export Function

To export (and convert) scope data, logged data, or Arb data (user-defined or CD), press the File key,
then scroll to and select Export.
Parameter
Type
Path\File Name
Browse
Export

Import Function

To import (and convert) Arb data (user-defined or CD), press the File key, then scroll to and select
Import.
168
Description
Data type: scope data, logged data, or Arb (User or CD). All data is exported in .csv format (comma sep-
arated values).
Specifies a file name in which to export the data.
Internal:\ specifies the instrument's internal memory.
External:\ specifies the Memory port on the front panel.
Enter a name in the text field. See Enter the File
Lets you browse another directory or USB memory device.
Exports the data to the file name in .csv format.
Name.
Keysight N6705C Operating and Service Guide
