- Page 1 Keysight N9041B Signal Analyzer Option EDC External Digitizer Control Installation Note...
- Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 3 Option EDC Upgrade Option EDC Upgrade Products Affected: N9041B UXA Signal Analyzer Serial Numbers: Options Required: N9041B-CRW, IF Output, Ultra-Wide Bandwidth To Be Performed By: ( ) Keysight Service Center (X) Personnel Qualified by Keysight (X) Customer Estimated Installation Time: 0.5 Hours...
- Page 4 Output, Option CRW) to be used with an oscilloscope and Keysight VSA measurement software. This installation note provides instructions for licensing Option EDC on the N9041B. No instructions are provided on the configuration and use of the oscilloscope and VSA software.
- Page 5 Verify that N9041B-CRW is checked (currently installed). If N9041B-CRW is not installed, do not proceed with the installation of this kit. Option CRW, IF Output, Ultra-Wide Bandwidth, is required to enable the rear panel Ext IF Out port. For information on how to order Option CRW refer to the N9041B upgrade page at: http://www.keysight.com\find\N9041B_upgrades...
- Page 6 Option EDC Upgrade Installation Procedure over USB 1. Locate the Option Upgrade Entitlement Certificate (5964-5178) from the kit. 2. Redeem the Option Upgrade Entitlement Certificate by following the instructions on the Certificate. 3. After redeeming your Option Upgrade Entitlement Certificate you will receive an email with an attached License File.
- Page 7 1. Cycle the power on the signal analyzer. 2. Press System, Show System to display a list of installed options. 3. Verify that the newly installed option, N9041B-EDC, External Digitizer Control, appears on the list. 4. Verify that Option N9041B-CRW also appears. this assures Option CRW is installed since Option EDC requires Option CRW.
- Page 8 This information is subject to change without notice. © Keysight Technologies 2018 Edition 1, April 2018 N9041-90008 www.keysight.com...
