Low Range Voltage Measurement - Models N6781A, N6782A, N6784A
Step 1. Select the low-voltage measurement range. The value entered must be the maximum voltage
of the range to be calibrated. This example selects the 1 V range of output 1.
Front Panel Menu Reference
From the Calibration menu, select Voltage, Low Range Measurement. Then select
Start.
Step 2. Select the first voltage calibration point and enter the data. This value may be positive or
negative.
Front Panel Menu Reference
Display shows: "Enter P1 measured data"Enter the data from the external DMM.
Press Select when done.
Step 3. Select the second voltage calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P2 measured data"Enter the data from the external
DMM.Press Select when done.
Press Next to finish calibration.
Step 4 applies only to models N6781A and N6782A
Step 4. Repeat steps 1 through 3 for the 100 mV range. This time, select the Low2 range.
Steps 5 and 6 apply only to model N6784A
Step 5. Select the third voltage calibration point for the negative range and enter the data. This value
should be negative.
Front Panel Menu Reference
Display shows: "Enter P3 measured data"
Enter the data from the external DMM. Press Select when done. Press Next to
finish calibration.
Step 6. Repeat steps 1 through 3, and 5 for the 100 mV range. This time, select the Low2 range.
Positive Voltage Limit - Models N6781A, N6782A, N6784A
Step 1. Select the positive voltage limit range. The value to program a range must be the maximum
voltage of the range to be calibrated. This example selects the 20 V positive limit range of output 1.
Front Panel Menu Reference
From the Calibration menu, select Voltage, Positive Voltage Limit. Then select
Start. Select the 20 V range.
Keysight N6705C Operating and Service Guide
8 Verification and Calibration
SCPI Command
CAL:VOLT:MEAS 1, (@1)
SCPI Command
CAL:LEV P1
*OPC?
CAL:DATA <data>
SCPI Command
CAL:LEV P2
*OPC?
CAL:DATA <data>
SCPI Command
CAL:LEV P3
*OPC?
CAL:DATA <data>
SCPI Command
CAL:VOLT:LIM:POS 20, (@1)
