Test Record Form - Keysight N6731B and N6741B
N6731B and N6741B
Test Description
Voltage Programming & Readback
Minimum voltage (Vout):
Voltage measured over interface:
High voltage (Vout):
Voltage measured over interface:
CV Load Effect:
CV Source Effect:
CV Ripple and Noise
peak-to-peak:
rms:
Transient response
Voltage @ 200 μs:
Voltage @ 200 μs with Option 760/761:
Current Programming & Readback
Minimum current (Iout):
Current measured over interface:
High current (Iout):
Current measured over interface:
CC Load Effect:
CC Source Effect:
Test Description
Voltage Programming & Readback Min Voltage:
Voltage Programming & Readback High Voltage:
CV Load Effect, Source Effect, Ripple and Noise:
Transient Response:
Current Programming & Readback Min Current:
Current Programming & Readback High Current:
CC Load Effect, Source Effect:
Keysight N6705C Operating and Service Guide
Report Number ______
Model Min. Specs
Constant Voltage Tests
Both − 4 mV
Both Vout − 20 mV
Both 4.976 V
Both Vout − 25 mV
Both – 5 mV
Both – 1 mV
N6731B N/A
N6741BBoth N/A
N/A
N6731B – 80 mV
N6741B – 100 mV
N6731B – 100 mV
N6741B – 125 mV
Constant Current Tests
Both + 40 mA
Both Iout − 20 mA
N6731B 9.965 A
N6741B 19.95 A
N6731B Iout − 35 mA
N6741B Iout − 50 mA
Both – 2 mA
Both – 1 mA
N6731B Setting
15 mV, 10 A
5 V, 10 A
5 V, 10 A
5 V, from 5 A to 10 A
60 mA, 5 V
10 A, 5 V
10 A, 5 V
8 Verification and Calibration
Date__________
Results Max. Specs
_______ + 34 mV
_______ Vout + 20 mV
_______ 5.024 V
_______ Vout + 25 mV
_______ + 5 mV
_______ + 1 mV
_______ + 10 mV
_______ +20 mV
_______ + 2 mV
_______ + 80 mV
_______ + 100 mV
_______ + 100 mV
_______ + 125 mV
_______ + 80 mA
_______ Iout + 20 mA
_______ 10.035 A
_______ 20.05 A
_______ Iout + 35 mA
_______ Iout + 50 mA
_______ + 2 mA
_______ + 1 mA
N6741B Setting
15 mV, 20 A
5 V, 20 A
5 V, 20 A
5 V, from 10 A to 20 A
60 mA, 5 V
20 A, 5 V
20 A, 5 V
