Product Nameplate; Model Description - INVT Goodrive300-01A Series Operation Manual

Goodrive300-01A series VFD for air compressor

2.2 Product nameplate

Note: This is a nameplate example of a standard model. CE, TUV, KC, and IP20 are marked
according to the actual certification condition.

2.3 Model description

The model code contains product information. Users can find the model code on the VFD nameplate
or simple nameplate.
GD300-01A–022G–4–E
Field
Abbreviation of
product series
Rated power +
Load type
Voltage class
Expandability
Model: GD300-01A-022G-4-E
Power(Output): 22kW
Input: AC 3PH 380V(-15%)-440V(+10%) 44A 47Hz-63Hz
Output: AC 3PH 0V-Uinput 45A 0Hz-400Hz
S/N:
Shenzhen INVT Electric Co.,Ltd.
Figure 2-1 Product nameplate
①
Figure 2-2 Product model
Table 2-1 Model description
Symbol Description
Abbreviation of
①
product series
Power class + Load
②
type
③
Voltage class
Optional
④
multi-function
expansion card
Made in China
②
Goodrive300-01A: GD300-01A VFD for
air compressor
022: 22kW
G: Constant torque load
2: AC 3PH 220V(-15%)–240V(+10%)
4: AC 3PH 3
80V(-15%)–440V(+10%)
6: AC 3PH 520V(-15%)–690V(+10%)
E: Optional multi-function expansion
card EC-IO304
