INVT Goodrive300-01A Series Operation Manual page 44

Goodrive300-01A series VFD for air compressor
Function
code
Starting frequency
P01.09 of DC braking for
Wait time before DC
P01.10
braking for stop
DC braking current
P01.11
for stop
DC braking time for
P01.12
FWD/REV running
P01.13
deadzone time
FWD/REV running
P01.14
switching mode
P01.15 Stop speed
Stop speed
P01.16
detection mode
Feedback speed
P01.17
detection time
Terminal-based
running command
P01.18
protection at
power-on
Action selected
when running
frequency less than
P01.19 frequency lower
limit (valid when
frequency lower
limit greater than 0)
Wake-up-from-sleep
P01.20
Power-off restart
P01.21
selection
Name
0.00–P00.03 (max. output frequency)
stop
0.00–50.00s
0.0–150.0%
0.00–50.00s
stop
0.0–3600.0s
0: Switch at zero frequency
1: Switch at the starting frequency
2: Switch after the speed reaches the stop
speed with a delay
0.00–100.00Hz
0: Detect as per the set speed value (judge
the ramps frequency)
1: Detect as per the speed feedback value
(valid for vector control only)
0.00–100.00s (valid only when P01.16=1)
0: The terminal running command is invalid
at power-on
1: The terminal running command is valid at
power-on
0: Run at the frequency lower limit
1: Stop
2: Sleep
0.0–3600.0s (valid when P01.14=2)
delay
0: Disable
1: Enable
Description
-38-
Function description
Default Modify
○
0.00Hz
○
0.00s
○
0.0%
○
0.00s
○
0.0s
◎
0
◎
5.00Hz
◎
1
◎
0.50s
○
0
◎
0
○
0.0s
○
0
