Goodrive300-01A series VFD for air compressor
Function
Name
code
High bit of initial
P08.48 value of power
consumption
Low bit of initial
P08.49 value of power
consumption
Flux braking
P08.50
coefficient
VFD input
P08.51
power factor

P09 group PID control

Function
Name
code
PID reference
P09.00
source
PID reference
preset
P09.01
through
keypad
PID feedback
P09.02
source
Description
0: Save the setting at power-off.
1: Clear the setting at power-off.
0–59999° ( k)
0.0–999.9 kWh
0: Disable
100–150: A larger coefficient indicates a
stronger brake intensity.
0.00–1.00
Description
0: Keypad digits (P09.01)
1: Analog P1-
2: Reserved
3: Analog P2-
4: Reserved
5: Multi-step
6: Modbus communication
7–9: Reserved
10: Pressure setting of dedicated function of
air compressor
-100.0%–100.0%
0: Analog P1-
1: Reserved
2: Analog P2-
3: Reserved
4: Modbus communication
5–7: Reserved
8: Pressure feedback of dedicated function of
air compressor
-66-
Function description
Default Modify
○
0kWh
○
0.0kWh
○
0
○
0.56
Default Modify
○
0
○
0.0%
○
0
