INVT Goodrive300-01A Series Operation Manual page 16

Goodrive300-01A series VFD for air compressor
Rated values of AC 3PH 520V(-15%)–690V(+10%) VFDs
Model
GD300-01A-022G-6-E
GD300-01A-030G-6-E
GD300-01A-037G-6-E
GD300-01A-045G-6-E
GD300-01A-055G-6-E
GD300-01A-075G-6-E
GD300-01A-090G-6-E
GD300-01A-110G-6-E
GD300-01A-132G-6-E
GD300-01A-160G-6-E
GD300-01A-185G-6-E
GD300-01A-200G-6-E
GD300-01A-220G-6-E
GD300-01A-250G-6-E
GD300-01A-280G-6-E
GD300-01A-315G-6-E
GD300-01A-350G-6-E
GD300-01A-400G-6-E
GD300-01A-500G-6-E
GD300-01A-560G-6-E
GD300-01A-630G-6-E
Note:

Input current of 22–350kW VFD models is the actually measured result under 660V input
voltage without DC reactor and input/output reactor.

Input current of 400–630kW VFD models is the actually measured result under 660V input
voltage with input reactor.

Rated output current is defined as the output current under 660V output voltage.

Under the allowable input voltage range, the output current shall not exceed its rated output
current, and the output power also shall not exceed its rated output power.
Output power
(kW)
22
30
37
45
55
75
90
110
132
160
185
200
220
250
280
315
350
400
500
560
630
-10-
Input current Output current
(A)
35
40
47
52
65
85
95
118
145
165
190
210
230
255
286
334
360
411
518
578
655
Product overview
(A)
27
35
45
52
62
86
98
120
150
175
200
220
240
270
300
350
380
430
540
600
680
