P11 Group Protection Parameters - INVT Goodrive300-01A Series Operation Manual

Goodrive300-01A series VFD for air compressor
Function
Name
code
Differential
P09.14
filter times

P11 group Protection parameters

Function
Name
code
Phase loss
P11.00
protection
Frequency drop at
P11.01
transient power dip
Frequency drop
P11.02 rate at transient
power dip
Overvoltage stall
P11.03
protection
Description
1: Stop integral regulation when the frequency
reaches upper/lower limit
LED hundreds:
0: The same with the set direction
1: Contrary to the set direction
0–60
Description
0x0000–0x1111
LED ones:
0: Disable input phase loss software
protection
1: Enable input phase loss software
protection
Note: LED ones place detects input phase
loss by phase sequence detection circuit.
LED tens:
0: Disable output phase loss protection
1: Enable output phase loss protection
LED hundreds:
0: Disable input phase loss hardware
protection
1: Enable input phase loss hardware
protection
Note: LED hundreds place detects input
phase loss by hardware detection circuit.
LED thousands:
0: Disable phase sequence protection
1: Enable phase sequence protection
0: Disable
1: Enable
0.00Hz–P00.03/s (max. output frequency)
0: Disable
1: Enable
-69-
Function description
Default Modify
○
2
Default Modify
○
0x0110
○
0
○
10.00Hz/s
○
1
