Goodrive300-01A series VFD for air compressor
A.3 Wall installation dimensions of 380V–440V VFDs
For VFDs of AC 3PH 380V (-15%)–440V (+10%)
Figure A-1 Wall installation diagram for 380V 7.5kW–37kW VFD models
Figure A-2 Wall installation diagram for 380V 45kW–55kW VFD models
W1
W2
W1
W2
W3
-112-
Product dimensions
D1
D2
D1
D2
