INVT Goodrive300-01A Series Operation Manual page 76

Goodrive300-01A series VFD for air compressor
Function
Name
code
Overvoltage stall
P11.04
protection voltage
Current limit
P11.05
selection
Automatic
P11.06
current-limit level
Frequency drop
P11.07
rate at current limit
Pre-alarm
selection for
P11.08
VFD/motor
overload/underload
Overload
pre-alarm
P11.09
detection level
Description
120–150% (standard bus voltage) (380V)
0x00–0x11
Ones: Current-limit action selection
0: Current-limit action is invalid
1: Current-limit action is always valid
Tens: Hardware current-limit overload alarm
selection
0: Hardware current-limit overload alarm is
valid
1: Hardware current-limit overload alarm is
invalid
50.0–200.0%
0.00–50.00Hz/s
0x000–0x131
LED ones:
0: Motor overload/underload pre-alarm,
relative to the motor rated current,
1: VFD overload/underload pre-alarm,
relative to the VFD rated current
LED tens:
0: The VFD keeps running after reporting an
overload/underload alarm.
1: The VFD keeps running after reporting an
underload alarm, but it stops running after
reporting an overload alarm.
2: The VFD keeps running after reporting an
overload alarm, but it stops running after
reporting an underload alarm.
3: The VFD stops running after reporting an
overload/underload alarm.
LED hundreds:
0: Always detect
1: Detect only in constant speed running
P11.11–200%
-70-
Function description
Default Modify
○
140%
◎
01
◎
160.0%
◎
10.00Hz/s
○
0x000
G type:
○
150%
