INVT Goodrive300-01A Series Operation Manual page 180

Goodrive300-01A series VFD for air compressor
Function
description
VFD fault code
VFD
identification
code
Running
frequency
The set
frequency
Bus voltage
Output voltage
Output current
Running speed
Output power
Output torque
Closed- loop
setting
Closed- loop
feedback
Input IO state
Output IO state
Analog input 1
Analog input 2
Analog input 3
Analog input 4
Read high
speed pulse 1
input
Read high
speed pulse 2
input
Address
definition
Bit4: =0: Non-overload pre-alarm
=1: Overload pre-alarm
Bit5– Bit6:
=00: Keypad control
=01: Terminal control
=10: communication control
2102H See fault type
GD300-01A (optional multi-function
2103H
expansion card)-----0x0132
3000H
3001H
3002H
3003H
3004H
3005H
3006H
3007H
3008H
Compatible with CHF100A, CHV100
3009H
communication address
300AH
300BH
300CH
300DH
300EH
300FH
3010H
3011H
Data meaning
-174-
Communication protocol
R/W
characteristics
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
