Goodrive300-01A series VFD for air compressor
Function
Name
code
RO5
P06.06 switch-on
delay
RO5
P06.07 switch-off
delay
RO3
P06.08 switch-on
delay
RO3
P06.09 switch-off
delay
RO1
P06.10 switch-on
delay
RO1
P06.11 switch-off
delay
RO2
P06.12 switch-on
delay
RO2
P06.13 switch-off
delay
AO1 output
P06.14
selection
Description
BIT4 BIT3
RO2 RO1
Setting range: 0–0x3F
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0: Running frequency
1: Set frequency
2: Ramp reference frequency
3: Running speed (relative to two times the
synchronous rotation speed of the motor)
4: Output current (relative to two times the
rated current of the VFD)
5: Output current (relative to two times the
-53-
BIT7 BIT6 BIT5
/ / RO6
BIT2 BIT1 BIT0
RO3 RO5 RO4
Function description
Default Modify
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
