Goodrive300-01A series VFD for air compressor
Figure A-17 Flange installation diagram for 660V 160kW–220kW VFD models
Table A-5 Flange installation dimension of 660V 22kW–220kW VFD models (unit: mm)
Power W1 W2
22kW–45kW 270 130
55kW–132kW 325 200
160kW–220kW 500 180
A.7 Floor installation dimensions of 520V–690V VFDs
For VFDs of AC 3PH 520V (-15%)–690V (+10%)
Figure A-18 Floor installation diagram for 660V 250kW–350kW VFD models
W3 W4 H1 H2 H3 H4 D1
261 65.5 555 540 516 17 325 167
317 58.5 680 661 626 23 363 182
480 60 870 850 796 37 358 178.5
-119-
Product dimensions
Diameter
of Screw
D2
mounting specification
hole
7
9.5
11
M6
M8
M10
