Goodrive300-01A series VFD for air compressor
Step 2 Enter the system parameter setting interface.
According to the sensor configuration, set the pressure sensor parameters, temperature sensor
parameters, and oriented function parameters. Then return to the system configuration interface.
03.17 16:02:35 Master param setting
Motor type
Max frequency
Rated power
Rated frequency
Rated voltage
Rated current
Return
03.17 16:02:35
Master param setting
Stator resistor
Rotor resistor
Leakage inductance
Mutual inductance
No-load current
Param auto-tuning
Return
Figure B-52 Master parameter setting interface
03.17 16:02:35
System param setting
Max voltage limit
Uplimit freq press drop
Temp sensor channel
Power correct coeffi
Uplimit freq drop rate
Press sensor P1 uplimit
Return
Maintain Timeout
Press sensor channel
Press sensor P2 Uplimit
Return
Figure B-53 System parameter setting interface
AM
050.00 Mpa
0090.0 kW
050.00 Hz
000380 V
0176.0 A
Home Edit
00.030 Ω
00.025 Ω
00.006 mH
00.169 mH
0040.8 A
Home Edit
xxxx.x %
xxx.xx MPa
PT1
xxxxxx %
xxx.xx Hz
xxx.xx MPa
Home
Edit
xxxxxx h
P1
xxx.xx MPa
Home
