Goodrive300-01A series VFD for air compressor
Fault
Fault type
code
Expansion card
E-FS
Flash fault
Expansion card
E-SPI communication
Touch screen
communication
interrupted

6.2 Fault contents and solutions of air compressor equipment

Abnormal state and solutions of air compressor equipment:
P19.13 State type
BIT0=1 Air filter blocked
BIT1=1 Oil filter blocked
BIT2=1 Separator blocked
Precision splitter
BIT3=1
blocked
BIT8=1 Pressure pre-alarm
R/W error occurred to the
calibration parameters.
The expansion card Flash is
damaged.
There is no data transmission
between the expansion card
offline and the main control board.
485 communication port is
disconnected.
Air filter is abnormal.
Oil filter is abnormal.
Separator is abnormal.
Precision splitter is
abnormal.
Actual voltage is detected by
P1 to be larger than the
pre-alarm voltage set by
P18.17.
Possible cause
Possible cause
-106-
Fault information and fault handling
Solution
the current transformation
ratio (P21.01) is the same
with current transformer
nameplate.
• Actually detected fan
current is too large, it is
recommended to increase
the power.
• Check whether the fan
stalls.
Press STOP/RST to reset.
Replace the main control
board.
Check whether the pin header
between the expansion card
and the main control board is
loosened or disconnected.
Check whether
communication line is
loosened.
Solution
Check air filter after stop.
Check oil filter after stop.
Check the separator after
stop.
Check the precision splitter
after stop.
• Check whether solenoid
valve is normal.
• Check whether pressure
control parameters are set
correctly.
