INVT Goodrive300-01A Series Operation Manual page 71

Goodrive300-01A series VFD for air compressor
Function
Name
code
Integral time of
P08.43 digital
potentiometer
UP/DOWN
P08.44 terminal control
setup
UP terminal
frequency
P08.45
incremental
change rate
DOWN terminal
frequency
P08.46
decremental
change rate
Action selection
for frequency
P08.47
setup during
power down
Description
0.01–10.00s
0x00–0x221
LED ones: Frequency enabling selection
0: UP/DOWN terminal setup is valid
1: UP/DOWN terminal setup is invalid
LED tens: Frequency control selection
0: Valid only when P00.06=0
1: All frequency modes are valid
2: Invalid for multi-step speed when multi-step
speed takes priority
LED hundreds: Action selection during stop
0: Setting is valid.
1: Valid during running, cleared after stop
2: Valid during running, cleared after a stop
command is received
0.01–50.00Hz/s
0.01–50.00Hz/s
0x000–0x111
LED ones: Action selection at power-off
during frequency adjusting through digitals.
0: Save the setting at power-off.
1: Clear the setting at power-off.
LED tens: Action selection at power-off during
frequency adjusting through Modbus
communication
0: Save the setting at power-off.
1: Clear the setting at power-off.
LED hundreds: Action selection at power-off
during frequency adjusting through other
communication
-65-
Function description
Default Modify
○
0.10s
○
0x000
○
0.50Hz/s
○
0.50Hz/s
○
0x000
