P13 group Synchronous motor control parameters

Function
Name
code
Pull-in current
P13.00 reduction
coefficient
Initial magnetic
P13.01 pole detection
mode
P13.02 Pull-in current 1
P13.03 Pull-in current 2
Description
0.1–3600.00s
0%–P11.09
0.1–3600.0s
0x00–0x11
LED ones:
0: Act during undervoltage fault
1: Do not act during undervoltage fault
LED tens:
0: Act during automatic reset period
1: Do not act during automatic reset period
0.0–50.0%
0.0–10.0s (Speed deviation protection is
disabled when P11.15 is set to 0.0.)
0: Invalid
1: Valid
Description
0.0–100.0%
0: Do not detect
1: High-frequency superposition (reserved)
2: Pulse superposition (reserved)
0.0%–100.0% (of the rated current of the
motor)
0.0%–100.0% (of the rated current of the
motor)
-71-
Function description
Default Modify
○
1.0s
○
50%
○
1.0s
○
0x00
○
10.0%
○
0.5s
○
1
Default Modify
○
50.0%
◎
0
○
20.0%
○
10.0%
