INVT Goodrive300-01A Series Operation Manual page 63

Goodrive300-01A series VFD for air compressor
Function
Name
code
Selection 2 of
parameters
P07.06
displayed in
running state
Selection of
parameters
P07.07
displayed in
stopping state
Frequency
P07.08
display coefficient
Rotational speed
P07.09
display coefficient
Linear speed
P07.10
display coefficient
Temperature of
P07.11 rectifier bridge
module
Temperature of
P07.12
inverter module
Description
0x0000–0xFFFF
BIT0: Analog P1- value (V on)
BIT1–BIT3: Reserved
BIT4: Motor overload percentage (% on)
BIT5: VFD overload percentage (% on)
BIT6: Ramp frequency reference value (Hz
on)
BIT7: Linear speed
BIT8: AC incoming current
BIT9–15: Reserved
0x0000–0xFFFF
BIT0: Set frequency (Hz on, frequency blinks
slowly)
BIT1: Bus voltage (V on)
BIT2: Input terminal state
BIT3: Output terminal state
BIT4: PID reference value (% blinks)
BIT5: PID feedback value (% on)
BIT6: Torque setting value (% on)
BIT7: Analog P1- value (V on)
BIT8–BIT15: Reserved
0.01–10.00
Displayed frequency = Running frequency *
P07.08
0.1–999.9%
Mechanical rotation speed =120 * (Displayed
running frequency) × P07.09/(Number of
motor pole pairs)
0.1–999.9%
Linear speed = (Mechanical rotation speed)
× P07.10
0–100.0℃
0–100.0℃
-57-
Function description
Default Modify
○
0x0000
○
0x00FF
○
1.00
○
100.0%
○
1.0%
●
●
