INVT Goodrive300-01A Series Operation Manual page 68

Goodrive300-01A series VFD for air compressor
Function
Name
code
Low-voltage
P08.16 protection
threshold
Overvoltage
P08.17 pre-protection
threshold
Automatic
P08.18
restart delay
Low-voltage
P08.19 frequency limit
running time
High-frequency
current loop
P08.20
proportional
gain
High-frequency
P08.21 current loop
integral time
High-frequency
current loop
P08.23
switching
frequency
Keypad lock
P08.25
enable
Maintenance
P08.26
timing mode
SM
P08.27 optimization
mode selection
Description
0.0V–2000.0V
0.0V–2000.0V
0.0–6000.0s
0.0–6000.0s
0–20000
0–20000
0.0–100.0% (max. output frequency P00.03)
0: Do not lock keypad
1: Allow to lock keypad
Lock: Press PRG key+DATA key
simultaneously
Unlock: Keep DATA key pressed down and
then click V key by three times.
0: No timing during sleep
1: Timing during sleep
0: Enable
Applicable to surface-mounted synchronous
motors. The actual
-62-
values of P02.21
Function description
Default Modify
○
300.0V
○
780.0V
○
60.0s
○
60.0s
○
1000
○
1000
○
100.0%
○
0
○
0
○
1
