Product Overview; Product Specification - INVT Goodrive300-01A Series Operation Manual

Goodrive300-01A series VFD for air compressor

2.1 Product specification

Category
Power input
Output voltage (V)
Power
output
Output frequency
Low voltage
DC power
supply
output
Speed fluctuation
Running Torque response
control
performance
Overload capacity

2 Product overview

Function
Input voltage of
the VFD (V)
Rated input
current (A)
Rated input
frequency (Hz)
Efficiency
Rated output
current (A)
Rated output
power (kW)
(Hz)
+24V DC power
Control mode
Speed ratio
Speed control
precision
Starting torque
Frequency
reference mode
Analog pressure
input
3PH 220V (-15%)–240V (+10%); Rated voltage: 220V
3PH 380V (-15%)–440V (+10%); Rated voltage: 380V
3PH 520V (-15%)–690V (+10%); Rated voltage: 660V
Refer to section 2.4 "
50Hz or 60Hz; allowed range: 47–63Hz
> 97%
Equal to input voltage, error ratio: less than 5%
Refer to section 2.4 "
Refer to section 2.4 "
0–400Hz
24W (rated value: 24V/1A)
Open loop vector, SVPWM
Asynchronous motor: 1:200 (SVC);
Synchronous motor: 1:200 (SVC)
±0.2% (SVC)
±0.3% (SVC)
<20ms (SVC)
Asynchronous motor: 0.25Hz 150% (SVC)
Synchronous motor: 2.5Hz 150% (SVC)
PID control, Modbus communication, P1- and P2- analog
input, keypad digital input
1min at 150%
1 input (standard): P1+/P1-
1 input (optional): P2+/P2-
4–20mA/0–1.6MPa input
-5-
Specification
Rated specifications
Rated specifications
Rated specifications
Product overview
".
".
".
