INVT Goodrive300-01A Series Operation Manual page 51

Goodrive300-01A series VFD for air compressor
Function
Name
code
Setting source
of braking
P03.19
torque upper
Electromotive
torque upper
P03.20
limit set through
keypad
Braking torque
P03.21 upper limit set
through keypad
Weakening
coefficient in
P03.22
constant power
zone
Lowest
weakening
P03.23 point in
constant power
zone
Max. voltage
P03.24
Pre-exciting
P03.25
Flux-weakening
P03.26 proportional
4: Reserved
5: Modbus communication (same as the
above)
6–8: Reserved
0: Keypad (P03.21)
1: P1- (100% corresponding to three times
the motor rated current)
2: Reserved
3: P2- (100% corresponding to three times
the motor rated current)
limit 4: Reserved
5: Modbus communication (same as the
above)
6–8: Reserved
0.0 –300.0% (of the motor rated current)
0.0 –300.0% (of the motor rated current)
0.1–2.0
10%–100.0%
0.0–120.0%
limit
0.000–10.000s
time
0–8000
gain
Description
-45-
Function description
Default Modify
○
0
○
180.0%
○
180.0%
○
0.3
○
20%
○
100.0%
○
0.300s
○
300
