INVT Goodrive300-01A Series Operation Manual page 54

Goodrive300-01A series VFD for air compressor
Function
Name
code
function
selection
P05.04 Function of S4
P05.05 Function of S5
P05.06 Function of S6
P05.07 Function of S7
P05.08 Function of S8
Input terminal
P05.10
polarity
Description
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Reset faults
8: Pause running
9: External fault input
10–24: Reserved
25: Pause PID control
26–39: Reserved
40: Clear electricity consumption
41: Keep electricity consumption
42: Air filter blockage signal
43: Oil filter blockage signal
44: Separator blockage signal
45: Precision splitter blockage signal
46: External fault 1 (motor overtemperature)
47: External fault 2
48: Fan running control signal
49: Solenoid valve control signal
50: Cooling fan control signal of main motor
51: PTC signal
52: Low water level detection (only for water
lubrication)
53: Medium water level detection (only for
water lubrication)
54: High water level detection (only for water
lubrication)
55: Extra water level detection (only for water
lubrication)
51–63: Reserved
The function code is used to set the polarity of
input terminals.
When a bit is 0, the input terminal is positive;
when a bit is 1, the input terminal is negative.
BIT4 BIT3
S5 S4
-48-
BIT7 BIT6 BIT5
S8 S7 S6
BIT2 BIT1 BIT0
S3 S2 S1
Function description
Default Modify
◎
0
◎
0
◎
0
◎
0
◎
0
○
0x00
