Goodrive300-01A series VFD for air compressor
Master parameter
Upper limit of
running frequency
Lower limit of
running frequency
Loaded running
frequency lower limit
Empty-load running
frequency
ACC time
DEC time
2. You can edit parameters only after entering a correct administrator password.
Initial value
50.00Hz
00.00Hz
40.00Hz
38.00Hz
Model
depended
Model
depended
03.17 16:02:35
Please enter current password:
Return
Figure B-36 Administrator password input interface
03.17 16:02:35
Set value
Max. 600.00 MPa
Min. 000.00 MPa
Return
Figure B-37 Maximum output frequency setting interface
It indicates the upper limit of the output frequency of
the VFD.
It indicates the lower limit of the output frequency of
the VFD.
It indicates the minimum working frequency that is
allowed to output when the pressure exceeds the
set value but does not reach the unloading pressure
during regulation.
It indicates the working frequency when the air
compressor is empty loaded.
It indicates the time taken by the VFD to accelerate
from 0Hz to the maximum frequency.
It indicates the time taken by the VFD to decelerate
from the maximum frequency to 0Hz.
0
000
Home
Max Output Freq
x
xxx.x Hz
